Taylor-Dunn BIGFOOT 48V
- Environment: Indoors
- Power: Electric
Not available
Not available
Additional standard features include our GT Drive system, 48 volt AC power, hydraulic disc brakes, regenerative braking, Smart View display, recessed tie-downs, 12 gauge smooth skin, unitized steel body, LED lighting, cupholders, and a heavy duty all gear drive train that ensures reliability and low maintenance costs. This vehicle can be configured to tow 17,500 pounds.
| Specification | Value |
|---|---|
| Dimensions: Outside Turning Radius: | 137″ (3480 mm) |
| Chassis: Tires: | Rear: 5.7 x 8, Load Range C, Pneumatic Front: 5.7 x 8, Load Range C, Pneumatic |
| Chassis: Brakes: | Rear: Hydraulic Disc Front: Parking: Y |
| Chassis: Battery: | Type: 210 Amp Hour, T605, 8 each, 6 volt System Voltage: 48V Charger: Built In, 48V, 115 VAC / 60 Hz, 1kW w/ Interlock, 17 Amp SCR |
| Dimensions: Deck: | Width: 44″ (1117 mm) Length: 77″ (1955 mm) Height: 27.5″ (698 mm) |
| Performance: Passengers: | 2 |
| Dimensions: Wheel Base: | 62″ (1574 mm) |
| Performance: Range: | 40 Miles (64 km) |
| Dimensions: Length: | 130.5″ (331 cm) |
| Chassis: Frame Construction: | 12 Gauge, Smooth Skin, Unitized, Fully Welded, Steel |
| Performance: Speed: | 12 mph (19.3 km/h) |
| Dimensions: Weight: | 1,565 lbs (710 kg.) |
| Chassis: Suspension: | Rear: Multi-Leaf Springs Front: Multi-Leaf Springs |
| Chassis: Powertrain: | Type: Electric Power: 115 VAC, 60 Hz Transmission: Helical Gear, Oil Bath Transaxle, GT Automotive Differential Drive: Controller: Solid State Self Diagnostic AC Speed Controller |
| Chassis: Steering: | Rack and Pinion |
| Performance: Tow Capacity: | 7,500 lbs (3402 kg) |
| Dimensions: Width: | 44″ (112 cm) |
| Interior: Instrumentation: | Smart View Display, Reverse Buzzer, Forward / Off / Reverse Selector, Key Switch, Light Switch, High / Low Speed Switch, Electric Horn, Emergency Power Cut-off Switch, USB Port, DC/DC Converter |
| Interior: Seats: | Driver: Black Adjustable Bucket Seat, Driver’s Seat Electrical Interlock Passenger: Black Adjustable Bucket Seat |
| Performance: Load Capacity: | 3,000 lbs (1361 kg) |
| Dimensions: Height: | Less Cab: 51.5″ (131 cm) With Cab: 73″ (1854 mm) |
