Multidirectional Forklifts
Combilift C5000STE
The multi-directional, electric stand-on forklift designed for the safe, space saving and productive handling of long and bulky loads.
- Max Lift Height: 159"
- Power: Diesel
FEATURES INCLUDE:
- Rubber Mounted Cabin
- Multi-Directional Operation
- AC Motor Technology
- Load Sensing Steering
- 2 Wheel Electric Drive
- Stand-up Operator
- (Sit Down Cabin Option Available)
- Adjustable Guide Rollers
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
| Specification | Value |
|---|---|
| Specifications – Ramp Angle: | 17 degrees |
| Specifications – Minimum Outside Radius: | 73 1/2″ |
| Specifications – Overhang Back: | 5 1/4″ |
| Specifications – Forward Tilt: | 4 degrees |
| Specifications – Overall Length: | 78 3/4″ |
| Specifications – Length From Face of Fork: | 31 1/2″ |
| Specifications – Platform Width: | 104″ |
| Specifications – Max. Lift Height: | 159″ |
| Specifications – Height Mast Closed: | 111.5″ |
| Specifications – Freelift Height: | 0″ |
| Specifications – Platform Length: | 47 1/4″ |
| Specifications – Platform Height: | 19″ |
| Specifications – Ground Clearance Under Mast: | 9″ |
| Specifications – Frame Opening: | 48 1/2″ |
| Specifications – Ground Clearance to Wheelbase: | 6″ |
| Specifications – Outside Spread of Fork Arms: | 45 1/4″ |
| Specifications – Track Front: | 82″ |
| Specifications – Departure Angle: | 45 degrees |
| Specifications – Max. (Mast raised): | 204″ |
| Specifications – Load Center Distance: | 23 1/2″ |
| Specifications – Backward Tilt: | 4 degrees |
| Specifications – Wheelbase: | 62 1/4″ |
| Specifications – Mast Travel: | 51″ |
| Specifications – Height Over Cab (without work lights): | 107.5″ |
| Specifications – Overhang Front: | 9 1/2″ |
| Specifications – Approach Angle: | 45 degrees |
