Motrec MX-480 Maintenance Truck
This dependable work truck adapts to a wide variety of jobs. Use it to access restricted spaces, or to quickly cover long distances much faster than on foot. The full-sized 7-drawer tool chest and large lockable compartments will hold all the parts and tools you need—and keep them safely where they belong. Standard features also include a bolt-on front bumper, ladder rack, tank rack, extinguisher & vice. Several option packages available. Unlimited configurations.
Not available
Not available
- AC controller with sealed connectors paired with multifunction display: Allows for precise speed control for greater safety and vehicle performance. Includes indicators for speed, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.
- Reinforced bolt-on front bumper: Protects vehicle components from damage and keeps maintenance costs low. Equipped with anchors for easier towing. Bumpers are easy to replace when needed. An easy, low-cost way to protect your investment.
- Safe and comfortable all-steel cabs: Protects operators and everyone around them. Our customizable cabs come with a long list of standard and optional features: lockable/Mika/removable doors, canopy top, ladder/pipe rack, wipers, rear-view mirror, sliding windows with safety glass, heater, air conditioning, cab-mounted strobe light, cab sound proofing, rust proofing… the list goes on and on.
- Console on steering column: Complete console on steering column to put all controls and displays conveniently right where your fingers and eyes are. Now with a tilted steering column for a more ergonomic and natural driving posture to reduce operator fatigue and strain.
- High-efficiency asynchronous AC / Direct Drive motor: Offers better control for full motor performance, as well as higher possible speeds and better torque at low speeds. Maintenance-free brushless electric motor equipped with temperature and speed sensors.
| Maintenance Truck | |
|---|---|
| Passengers | 2 |
| Load Capacity | 2,750 lbs. |
| Towing Capacity | 6,000 lbs. |
| Speed | 10 mph |
| Turning Radius | 133″ |
| Motor | Brushless AC motor, HP (9 HP continuous) |
| Drive Axle | Helical gear differential |
| Transmission | Direct drive |
| Controller | AC Electronic speed controller |
| ENERGY | |
| Voltage | 48V |
| Battery | Eight 6V-225AH batteries |
| Charger | High-frequency (85-265VAC / 45-65Hz, 1kw), built-in automatic. |
| CHASSIS | |
| Body | All-steel unibody construction. Powder coating |
| Suspension | Dual leaf springs on front and rear |
| Brakes | Rear hydraulic drum brake, electromagnetic parking brake with manual hand release, regenerative braking |
| Wheels | 5.7×8 LRD pneumatic tires |
| Steering | Automotive steering wheel, tilted steering column |
| Seats | Two premium seats on slide adjusters |
| EQUIPMENT | |
| Lights | LED dual headlights & tail/brake lights, dual back-up lights |
| Indicators | Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability. |
| Accessories | Console on steering column, bolt-on front bumper, DC/DC converter to equalize battery cells, LED charge indicator, full-sized 7-drawer tool chest, 3 lockable compartments, ladder/pipe racks, extinguisher, vice |
| Safety | Deadman seat switch, reverse alarm, horn, automatic parking brake |
| VEHICLE | |
| Weight | |
| Height | 86,5″ |
| Length | 126,5″ |
| Width | 45,5″58″ |
| Wheel Base | |
| DECK | |
| Deck Height | 42,5″ |
| Deck Length | 79″ |
| Deck Width | 45,5″ |
| BATTERY | |
| Battery Weight | |
| Battery Height | |
| Battery Length | |
| Battery Width | |
